Material: Made with high-quality stianless steel wire: SUS304, 304L, 316, 316L. or product in brass wire, nickel wire, and if you need other metal materials we also can in accordance with your quantity.

Weave ways: divided Dutch Plain Weaving, Dutch Twill Weaving or Dutch Reverse Weaving.

Dutch Twill Weave: Each weft wire passes alternately over two, and then under two successive warp wires and each warp wire passes alternately over two and under two successive weft wires. It is possible to be used to allow a heavier than standard wire diameter.

Dutch Reverse Weave: Dutch Reverse Weave is the same as Dutch weave except the warp and weft wires are reversed.

Featute: Good wear-resistance, Heat-resistance, Acid-resistance, Corrosion resistance and characteristics.

Application: The prodcution is mainly applied to filter  chemical industry, medicine, petroleum, telecom-communication, scientific research units or other applications.

Dutch Wire Cloth Plain Woven
Gauge No.	Mesh/Inch (Warp x Weft)	Wire Diameter (Warp x Weft)	Reference Aperture (um)	Weight/sq (kg)
32#	8 x 62	0.63mm x 0.45mm	300	5.42
40#	10 x 79	0.50mm x 0.355mm	250	3.16
48#	12 x 64	0.58mm x 0.40mm	280	2.9
55#	14 x 88	0.40mm x 0.30mm	180	2.54
76#	19 x 140	0.315mm x 0.20mm	140	1.88
80#	20 x	0.35mm x 0.20mm	-	3.6
95#	24 x 300	0.355mm x 0.25mm	120	2.45
100#	25 x 140	0.28mm x 0.20mm	100	1.95
120#	30 x 150	0.25mm x 0.18mm	80	1.68
140#	35 x 175	0.224mm x 0.16mm	71	1.52
160#	40 x 200	0.20mm x 0.14mm	60	1.40
180#	45 x 250	0.16mm x 0.112mm	56	1.09
200#	50 x 250	0.14mm x 0.11mm	53	1.04
220#	55.5 x 280	0.14mm x 0.10mm	50	0.92
240#	65 x 330	0.11mm x 0.08mm	36	0.71
280#(1)	70 x 350	0.11mm x 0.08mm	35	0.72
280#(2)	70 x 385	0.11mm x 0.07mm	32	0.75
300#	78 x 700	0.11mm x 0.08mm	30	1.39
315#(1)	80 x 400	0.10mm x 0.065mm	40	0.62
315#(2)	80 x 600	0.10mm x 0.06mm	-	-
315#(3)	80 x 800	0.15mm x 0.04mm	-	-
Roll width: 1-1.6m

Dutch Wire Cloth Twill Woven
Gauge No.	Mesh/Inch (Warp x Weft)	Wire Diameter (Warp x Weft)	Reference Aperture (um)	Weight/sq (kg)
320#	81 x 780	0.10mm x 0.07mm	30	1.22
354#	90 x 550	0.12mm x 0.05	-	-
360#	91 x 787	0.10mm x 0.10	25	1.24
400#	101 x 900	0.10mm x 0.10	20	1.22
472#	120 x 400	0.10mm x 0.10	-	-
500#	127 x 1100	0.07mm x 0.07	17	0.81
630#	160 x 1500	0.063mm x 0.063	15	0.62
650#(1)	165 x 400	0.017mm x 0.017	-	-
650#(2)	165 x 600	0.017mm x 0.017	-	-
650#(3)	165 x 800	0.017mm x 0.017	25	-
650#(4)	165 x 1100	0.017mm x 0.017	-	-
650#(5)	165 x 1400	0.017mm x 0.017	16	0.76
685#	174 x `700	0.063mm x 0.063	13	0.61
787#(1)	200 x 600	0.071mm x 0.071	-	-
787#(2)	200 x 800	0.071mm x 0.071	-	-
787#(3)	200 x 1400	0.071mm x 0.071	12	0.8
795#	202 x 1760	0.05mm x 0.05	10	0.6
850#	216 x 1860	0.045mm x 0.045	9	-
1000#	254 x 2000	0.04mm x 0.04	8	0.5
1125#	285 x 2235	0.036mm x 0.036	7	-
1228#	312 x 2100	0.035mm x 0.035	-	-
1250#	318 x 2235	0.036mm x 0.036	-	-
1280#	325 x 2300	0.035mm x 0.035	5	0.45
1575#	400 x 33100	0.035mm x 0.035	3	-
Roll width: 1-1.6m
