The soft and malleable properties of copper wire mesh make it ideal for woven wire mesh and wire cloth.

It is often used in industry for its properties of high electrical conductivity and thermal conductivity as it conducts heat up to eight times better than other commonly used metals.

Copper is one of only four elemental metals with a natural colour other than grey or silver which makes it ideal for many decorative applications. The raw metal has a red-orange colour, which changes on exposure to the elements. Exposure creates a distinctive natural green verdigris or patina used to effect by architects and designers. The final patina is a particularly durable layer that is highly resistant to atmospheric corrosion, thereby protecting the underlying metal against further weathering.

Material: Brass wire, phosphor bronze wire, or copper wire.

Specifications:
brass wire cloth 6 mesh/inch - 160 mesh/inch;
copper wire cloth 10 mesh/inch - 60 mesh/inch;
phosphor bronze wire cloth 120 mesh - 360 mesh/inch.

Width: 0.914M, 1M, 1.5M.

Length/roll: 30M.

Weaving methods: plain weave, twill weave or dutch weave.

Application: Seperation and sifting kinds pellet, grain, porcelain earth and glass, chinaware printing, filter liquid, etc.

Mesh	Wire Dia.			Opening(mm)
	SWG	mm	inch
6	22	0.711	0.028	3.522
8	23	0.610	0.024	2.565
10	25	0.508	0.020	2.032
12	26	0.457	0.018	1.660
14	27	0.417	0.016	1.397
16	29	0.345	0.014	1.243
18	30	0.315	0.012	1.096
20	30	0.315	0.0124	0.955
22	30	0.315	0.0124	0.840
24	30	0.315	0.0124	0.743
26	31	0.295	0.0116	0.682
28	31	0.295	0.0116	0.612
30	32	0.247	0.011	0.573
32	33	0.254	0.010	0.540
34	34	0.234	0.0092	0.513
36	34	0.234	0.0092	0.472
38	35	0.213	0.0084	0.455
40	36	0.193	0.0076	0.442
42	36	0.193	0.0076	0.412
44	37	0.173	0.0068	0.404
46	37	0.173	0.0068	0.379
48	37	0.173	0.0068	0.356
50	37	0.173	0.0068	0.335
60×50	36	0.193	0.0076	-
60×50	37	0.173	0.0068	-
60	37	0.173	0.0068	0.250
70	39	0.132	0.0052	0.231
80	40	0.122	0.0048	0.196
90	41	0.112	0.0044	0.170
100	42	0.012	0.004	0.152
120×108	43	0.091	0.0036	-
120	44	0.081	0.0032	0.131
140	46	0.061	0.0024	0.120
150	46	0.061	0.0024	0.108
160	46	0.061	0.0024	0.098
180	47	0.051	0.002	0.090
200	47	0.051	0.002	0.076
